Delivery of Zhongyuan 6 sets roll forming machine On Nov, 13,2021 To India

Author:Site Editor     Publish Time: 2021-11-15      Origin:Site Inquire

6 sets roll forming machine to India as following(including panel roll forming machine、seaming roll forming machine、decking roll forming machine、cz purlin machine、crimping roll forming machine、downpipe forming machine):


1.Seaming roll forming machine components:

(1) Manual decoiler                        1 set(Capacity: 5 tons)

(2) Roll-Forming M/C                       1 set

(3) Hydraulic Cutting                       1 set

(4) Hydraulic station                         1 set

(5) PLC Control System                     1 set

(6) Product Rack (un-powered)                1 set (two pieces, total length is 3 meters)


2.CZ purlin roll forming machine components:

(1) Double conic manual decoiler             1 set (Capacity: 5 tons)

(2) Leveling device                         1 set (4 upper+5 down structure)

(3) Punching device                         2 set

(4) Cutting device                           1 set

(5) Roll-Forming M/C                        1 set

(6) Hydraulic station                         1 set

(7) PLC control system                     1 set

(8) Product Rack (un-powered)              1 set (two pieces, total length is 3 meters)

(9) Tool Box                                1 set


3.panel roof machine components:

(1) Hydraulic decoiler                       1 set(Capacity: 10 tons)

(2) Roll-Forming M/C                       1 set

(3) Hydraulic Cutting                       1 set

(4) Hydraulic station                         1 set

(5) PLC Control System                     1 set

(6) Stacker                                 1 set (11.8meters)

(7) Tool Box                                1 piece


4.crimping roll forming machine components:

(1) Crimping machine                        1 set

(2) Hydraulic station                         1 set

(3) PLC Control System                     1 set

(4) Feeding rollers                           3 stations


5.downpipe roll forming machine components:

(1) Manual decoiler                         1 set(Capacity: 5 tons)

(2) Roll-Forming M/C                        1 set

(3) Cutting system                         1 set

(4) Bending system                          1 set

(5) Neck Device                            1 set

(6) Hydraulic station                         1 set

(7) PLC Control System                     1 set

(8) Product Rack (un-powered)                 1 set (two pieces, total length is 3 meters)


6.deck roll forming machine components:

(1) Manual decoiler                         1 set(Capacity: 10 tons)

(2) Roll-Forming M/C                        1 set

(3) Hydraulic Cutting                       1 set

(4) Hydraulic station                         1 set

(5) PLC Control System                     1 set

(6) Product Rack (un-powered)               1 set


1.CZ purlin Roll Forming Machine Main Technical Parameters:

1) Suitable Coil Thickness:        1.5-3.0mm

2) Max. Coil Width:              as per drawing

3) Suitable Raw Materials:       galvanized steel coils

4) Yield Strength of Raw Material:   235Mpa

5) Panel Length                  >3000mm

6) Forming Speed:               Max. about 18m/min.(not include punching and cutting)

7) Main Motor Power:           5.5X4KW

8) Hydraulic station motor power:   11KW

9) Manual Decoiler               Max. Capacity: 5000kgs

10) Control system                Mitsubishi PLC and Frequency converter

11) Machine layout dimension     about 20m×2.1m×1.65m


2.Floor deck Roll Forming Machine Main Technical Parameters:

1) Forming Speed:              Max. About 20-25m/min. (excluding the cutting time)

2) Main Motor Power:           11KWX2 (Depend on final design)

3) Hydraulic Station Power:       5.5KW (Depend on final design)

4) Control System:              Mitsubishi PLC and transducer (Japan)

5) Encoder:                   Nemicon (Japan)

6) Rollers’ material            High grade No.45 forged steel, with digital-controlled procession,plated wit chrome on surface.

7) Shaft diameter              90mm, tooled by grinding machine for two times to ensure the precision of final product.

8) Type of Cutting:             Length-set cutting and post forming style

9) Electric Condition:           415V/3Phase/50HZ(or depend on customer)

10) Total Weight:               About 18500 Kg


Packing pictures:

forming machine

hydraulic decoiler

making machine

panel forming machine

decking roll forming machine

machine

panel roll forming machine

roll making machine

seaming roll forming machine
